2192Y Class 5 Conductor PVC Electrical Cable 300V Flat For Kitchen Office

Name: 2192Y Class 5 Conductor PVC Electrical Cable 300V Flat For Kitchen Office
Brand: UNI-CABLES
Price: 1 USD

Brand Name : UNI-CABLES

Model Number : 2192Y

Certification : CCC,ISO9001

Place of Origin : CHINA

MOQ : 200 Rolls

Price : Depends on Quantity

Supply Ability : 10000 Rolls per Week

Packaging Details : 100 Meters per Roll

Voltage Rating (Uo/U) : 300/300V

Temperature Rating : 5°C to +70°C

Minimum Bending Radius : 8 x overall diameter

Sheath Colour : White Black

Conductor : Class 5 flexible copper conductor

Insulation : PVC (Polyvinyl Chloride)

Sheath : PVC (Polyvinyl Chloride)

Contact Now

BS EN 50525-2-11 PVC Electrical Cable Type 2192-Y 300V PVC Flat Flexible Cable

2192Y Class 5 Conductor PVC Electrical Cable 300V Flat For Kitchen Office

APPLICATION
Light duty cable for use in domestic premises, kitchens and offices. For use as pendant light drops and light supply leads.

CABLE STANDARDS
BS EN 50525-2-11 (previously BS 6500),
BS EN/IEC 60332-1-2

DIMENSIONS

NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL THICKNESS OF INSULATION mm	NOMINAL THICKNESS OF SHEATH mm	NOMINAL OVERALL DIAMETER H x W mm	NOMINAL WEIGHT kg/km
2	0.5	0.5	0.6	3.35 x 5	30
2	0.75	0.5	0.6	3.5 x 5.5	37

CONDUCTORS
Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables

NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM DIAMETER OF WIRES IN CONDUCTOR mm	MAXIMUM RESISTANCE OF CONDUCTOR AT 20ºC
NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM DIAMETER OF WIRES IN CONDUCTOR mm	Plain Wires ohms/km	Metal-Coated Wires ohms/km
0.5	0.21	39	40.1
0.75	0.21	26	26.7

ELECTRICAL CHARACTERISTICS
Current Carrying Capacity and Mass Supportable

NOMINAL CROSS SECTIONAL AREA mm²	CURRENT CARRYING CAPACITY		MAXIMUM MASS SUPPORTABLE BY TWIN FLEXIBLE CORD kg
NOMINAL CROSS SECTIONAL AREA mm²	Single-Phase AC Amps	Three-Phase AC Amps	MAXIMUM MASS SUPPORTABLE BY TWIN FLEXIBLE CORD kg
0.5	3	3	2
0.75	6	6	3

Voltage Drop

NOMINAL CROSS SECTIONAL AREA mm²	DC OR SINGLE-PHASE AC mV/A/m	THREE-PHASE AC mV/A/m
0.5	93	80
0.75	62	54

DE-RATING FACTORS

AIR TEMPERATURE	35ºC	40ºC	45ºC	50ºC	55ºC
DE-RATING FACTOR	0.91	0.82	0.71	0.58	0.41
